90′ Boundless M/Y – Island Cruiser 2009 – MIGLIORI AMICI
Boundless Motor Yacht – Island Cruiser
Description
This rugged, exceedingly well built motor yacht blends form and function in a way that makes her ideal for Bahamas crusing and other island hopping. Her shallow 2′ 6″ draft and Hamilton waterjet drives make operating across the Bahama Bank a breeze, while at the same time affording comfortable access to the many interesting harbors and anchorages often denied to deeper draft vessels.
With very nearly eight feet of headroom and equally generous elbow room in all compartments, the Boundless 90 is well suited for spending extended periods of time aboard. Her cherry wood finish interior is inviting and relaxed, while her country-kitchen style galley facilitates convivial gatherings of family and friends. Large maindeck dining and living/entertainment areas flow together to eliminate any feeling of being cramped or confined in any way. Large windows and truly full sized doorways work to enhance the feeling that she is a much larger vessel than her 90 feet LOA.
On her lower deck, four large staterooms, each with bath en suite and huge closets, provide sleeping and private lounging accommodations for eight. And an outsized laundry/utility room, provides a center from which hired crew can properly service an owner’s party or a charter group, equally well.
The Boundless 90’s aft engine room is fitted with triple Yanmar marine diesel engines, coupled to Hamilton waterjet drives, for shallow water operation, high maneuverability, and ultimate flexibility of choice with respect to speed, fuel consumption, and range. Run on all three engines for top speed and performance. Use only the two wing engines for moderate speeds and docking maneuverability. And cut back to the single, centerline engine for passagemaking speeds and extended range.
The engine room itself is very large and roomy, again with nearly eight feet of headroom. Her engines and contained mechanical systems are readily accessible for proper regular maintenance; and she has been maintained in top condition since she was first commissioned. Engine hours are very low.
On deck, her full walkaround configuration enhances one’s feeling of dominion, and makes docking and line handling a snap. Her generous quarter deck is shaded and makes a superb outdoor entertainment area, while her exceedingly large, broad expanse of boat deck provides space for stowing a tender, jet skis, or other water toys, while still leaving ample room in and around her flybridge control station.
If you measure the value of your time on the water in terms of convenience, comfort, and relaxation, then this distinctive, sensible motor yacht will yield an ROI higher than you’ve seen in a long time.
Virtual Tours – Click & Drag Screen
Measurements
LOA: 90 ft
Beam: 22 ft
Max Draft: 2 ft 6 in
Cabin Headroom: 7 ft 11 in
Cruising Speed: 25 kn
Max Speed: 29 kn
Displacement: 110000 lb
Displacement Type: Half Load
Windlass: Hydraulic Windlass
Liferaft Capacity: 10
Fuel Tanks Capacity: 1500 gal
Fresh Water Tanks Capacity: 550 gal
Propulsion
Number of Engines: 3
Primary Engines: Inboard
Drive Type: Jet Drive
Engine Make: Yanmar
Engine Model: 65Y-STP
Engine Year: 2009
Engine Hours: 400
Total Power: 2160 hp
Features
Electronics
Depthsounder
Log-Speedometer
Wind Speed and Direction
Repeater(s)
Navigation Center
Plotter
Autopilot
Compass
GPS
VHF
Radar
Radar Detector
Computer
TV Set
VCR
DVD Player
Radio
CD Player
Cockpit Speakers
Inside Equipment
Stern Thruster
Bow Thruster
Electric Bilge Pump
Manual Bilge Pump
Air Compressor
Electric Head
Hot Water
Fresh Water Maker
Sea Water Pump
Dishwasher
Washing Machine
Oven
Microwave Oven
Air Conditioning
Heating
Refrigerator
Deep Freezer
Battery Charger
Electrical Equipment
Shore Power Inlet
Outside Equipment/Extras
Cockpit Shower
Life Raft
Cockpit Table
Generator
Tender
Cockpit Cushions
Swimming Ladder
ADDITIONAL DETAILED SPECIFICATIONS
LOA: 90′ (27.43m)
Beam: 22′ (6.71m)
Draft: 2’6″ (.762m)
Displacement: 110,000 lbs
Builder: Custom Steel Boats Inc.
Year: 2009 Naval
Architect: Robert C. Johnston, N.A. Interior
Designer: Donna Hoffman
Notable Appointments: 7′ 11″ headroom, cork flooring for exceptional insulation
Hull: Aluminum
Superstructure: FRP Composite Propulsion
Engines: (3) Yanmar 6SY-STP 720 HP marine diesels
Jet Drives: (3) Hamilton Model HJ403 jet drives
Marine Gears: (3) ZF350 transmissions w/ 1.286:1 reduction ratio and electric shift
Speed: 25 knots cruise, 29 knots WOT (at half-load)
Fuel Capacity: 1,500 U.S. gals
Water Capacity: 550 U.S. gals
Other Tankage: (2) 600 U.S. gals sewer tanks plus gray water collection tanks
Steering: Hamilton joystick docking system, port and starboard wing engines
Generators: (3) Northern Lights 20kW 120/240v
Air Conditioning: Cruisair chilled water w/ zone controls
ShorePower: (2) 100-amp w/ (2) power cords
Fire Supression System: FM-200 cylinder fire suppression system, USCG approved
Guests/Staterooms: (8) in four stateroom, plus (2) sleeper couches on main deck
Navigation/Communication Electronics:
Furuno NavNet 3D 12.1″ multi function display; Furuno 3.5′ UHD digital open array radar, 48nm, 4kW; Furuno autopilot with heading sensor; Furuno RD-30 remote depth display; Furuno P17 depth/ temp with 7 pin smart sensor; Furuno 8.4″ Multi Function Display NavNet 3D; Icom HM-157 Black Command Microphone; Icom M- 504 Black VHF
Entertainment Electronics:
KVH TracVision M3ST Satellite TV Antenna System w/12V Mobile DIRECTV receiver, KVH Destacker, Dual Output, KVH Splitter for additional 12v receivers, FM antenna Main salon: 40″ Sony Bravia HDTV, Bose Lifestyle 38 home entertainment unit w/surround sound, DVD/CD and AM/FM radio Master stateroom: Sony 32″ Bravia HDTV, Satellite receiver, Bose 321 home stereo CD/DVD system with expanded sound Twin bunk stateroom or Crew quarters: Sony 22″ Bravia HDTV, Satellite receiver with X-Box CDIDVD
Decks: Bose speakers w/amp from Bose Lifestyle 38 Pilothouse: Retractable 22″ Sharp TV with built in DVD Plate and receiver plus Bose speakers w/amp from Bose Lifestyle 38
Deck Equipment / Tenders:
Nautical Structures manual/electric davit 24VDC Aquarius Aquacat catamaran race boat w/ Merc 30-hp outboard engine and full cover Multi-colored LED lighting on exterior and decks ACR Searchlight (RCL-100) Kahlenberg D2 Air horn, Chrome Finish Swim platform hydraulic actuated swim ladder Kenyon electric grill w/electric elements and full cover
Disclaimer
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
